| Thickness mm | Height mt | Length mt |
| 3 | 1,20 | 10 |
| 4 | 1,20 | 10 |
| 5 | 1,20 | 10 |
| 6 | 1,20 | 10 |
| 8 | 1,20 | 10 |
| 10 | 1,20 | 10 |
| 15 | 1,20 | 5 |
| 20 | 1,20 | 5 |
| 4 | 1,50 | 10 |
| 5 | 1,50 | 10 |
| 6 | 1,50 | 10 |
| 8 | 1,50 | 10 |
| 10 | 1,50 | 10 |
View the embedded image gallery online at:
https://getechsrl.com/en/products/hyrax/sheets-flooring/l01g2t-sbr-double-cloth-inserted-sheet.html#sigProIde2b793c917
https://getechsrl.com/en/products/hyrax/sheets-flooring/l01g2t-sbr-double-cloth-inserted-sheet.html#sigProIde2b793c917
Hyrax - Outlet
Sheets and Flooring
L01G2T
SBR Double Cloth Inserted Sheet
SBR double cloth inserted rubber sheet suitable for general purposes, not indicated for chemicals, heat or special physical/mechanical properties; with a greater tearing resistance thanks to a double cloth insert.
Technical Features
COLOUR: Black
SURFACE: Smooth
SPECIFIC WEIGHT: 1,5 gr/cm3
HARDNESS: 70 Shore A
TENSILE STRENGHT: 3 Mpa
ELONGATION: 200 %
RANGE TEMPERATURE: - 20°C + 70°C
Weight Calculation
Length (meters) x Height (meters) x Thickness (millimeters) x Specific Weight = Kg total Sheet Example: 10 (lenght) x 1,5 (height) x 4 (thickness) x 1,5 (specific weight) = 90 kg
Available on request
